Sealing Cone CP020071/593 BFT Intensifier Valve Seat 5102203 Pump Spare Parts

Short Description:

BFT CP020071/593, Sealing Cone CP020071, Valve Seat 5102203
Alternative code (cross code): 5102203
Weight: 0.01 kg.
Working pressure: 4137 bar
Material: Stainless steel
Where is it located (in which unit, in which part of the equipment):
Element of the high-pressure pump intensifier.
What is the function (what is it for, what role):
Serves to release water from the intensifier.

INQUIRY

Details

Sealing Cone CP020071/593 BFT Intensifier Valve Seat 5102203 Pump Spare Parts

The CP020071/593 Sealing Cone is a precision-machined stainless-steel valve seat used in the high-pressure Intensifier Pump assembly of BFT waterjet systems.

Product Details
Part Number: CP020071/593
Cross-Reference Code: 5102203
Recommended For: BFT, Maximator, and STM Intensifier Pumps
Weight: 0.01 kg
Operating Pressure: Up to 4 137 bar (60 000 psi)
Material: Stainless-steel alloy
Installation Location: In the pressure-release valve assembly of the intensifier pump

Technical Specifications
Seal Geometry: Cone-shaped valve seat, precision-ground for leak-tight fit
Surface Finish: Ra ≤ 0.4 µm for optimal sealing
Temperature Range: –20 °C to +120 °C (typical for stainless-steel hydraulic components)
Compatibility: Direct OEM drop-in replacement for part 5102203
