Ruby Waterjet Orifice High Efficiency Waterjet Cutting Machine Nozzle Orifice

Product Introduction

Ruby Waterjet Orifice is a precision nozzle component used in ultra-High Pressure Waterjet cutting machines. It helps convert high-pressure water into a focused and stable cutting stream, improving cutting accuracy, edge quality, and production efficiency. Made from durable synthetic ruby material, this waterjet orifice offers good wear resistance, stable performance, and long service life for Industrial Waterjet applications.

This ruby nozzle orifice is suitable for abrasive waterjet cutting, pure waterjet cutting, metal fabrication, glass processing, ceramic cutting, stone cutting, and other precision cutting applications. KUNDA can supply different orifice sizes and specifications according to machine model, working pressure, and cutting requirements.

Ruby Waterjet Orifice Specifications

Part Number	Material	Orifice Size (mm)	Part Number	Material	Orifice Size (mm)	Part Number	Material	Orifice Size (mm)
A2260003	Sapphire	0.076	A2260004	Sapphire	0.102	015849-5	Diamond	0.127
A2260005	Sapphire	0.127	A2260006	Sapphire	0.152	003788-007	Sapphire	0.178
A2260007	Sapphire	0.178	A2260008	Sapphire	0.203	003788-008	Sapphire	0.203
A2260010	Sapphire	0.254	A2260011	Sapphire	0.279	304352-05	Sapphire	0.127
A2260012	Sapphire	0.305	A2260015	Sapphire	0.381	305322-13	Sapphire	0.330
A2260016	Sapphire	0.406	A2260020	Sapphire	0.508	305322-14	Sapphire	0.356
49888852	Diamond	0.076	49888860	Diamond	0.102	305322-15	Diamond	0.381
49888878	Diamond	0.127	49888886	Diamond	0.152	304352-16	Sapphire	0.406
49888894	Diamond	0.178	49888902	Diamond	0.203	304352-20	Sapphire	0.508
49888910	Diamond	0.229	49888928	Diamond	0.254	305322-07	Diamond	0.178
49888936	Diamond	0.305	49888951	Diamond	0.381	305322-10	Diamond	0.254
49836786	Diamond	0.330	49888969	Diamond	0.406	305322-12	Diamond	0.305
49888944	Diamond	0.356	49888977	Diamond	0.457	305322-20	Diamond	0.508
49888985	Diamond	0.508	05112537	Diamond	0.203	305322-22	Diamond	0.559
49888993	Diamond	0.559	05084504	Diamond	0.229	014201-013	Ruby	0.330
20448625	Diamond	0.102	05077029	Diamond	0.254	014201-010	Ruby	0.254
05063847	Diamond	0.178	05101753	Diamond	0.279	015849-10	Diamond	0.254
05077300	Diamond	0.305	05114897	Diamond	0.508	015849-13	Diamond	0.330
05136098	Diamond	0.330	20481407	Diamond	0.170	015849-14	Diamond	0.356
05077037	Diamond	0.356	20481408	Diamond	0.200	015849-15	Diamond	0.381
05121512	Diamond	0.406	20481409	Diamond	0.230	304352-10	Sapphire	0.254
05114905	Diamond	0.457	20481410	Diamond	0.250	304352-11	Sapphire	0.279
80086663	Diamond	0.482	20481411	Diamond	0.280	304352-12	Sapphire	0.305
20481413	Diamond	0.330	20481412	Diamond	0.300	304352-13	Sapphire	0.330
20481414	Diamond	0.350	20477959007	Diamond	0.170	304352-14	Sapphire	0.356
20481415	Diamond	0.380	20477959008	Diamond	0.200	304352-15	Sapphire	0.381
20481416	Diamond	0.400	20477959009	Diamond	0.230	20477959013	Diamond	0.330
20481418	Diamond	0.460	20477959010	Diamond	0.250	20477959014	Diamond	0.350
20477959011	Diamond	0.280	20477950008	Diamond	0.200	20477959016	Diamond	0.400
20477959012	Diamond	0.300	20477950009	Diamond	0.230	20477959018	Diamond	0.460
20477950010	Diamond	0.250	20477950013	Diamond	0.330	20477950007	Diamond	0.170
20477950011	Diamond	0.280	20477950014	Diamond	0.350	20477950016	Diamond	0.400
20477950012	Diamond	0.300	041759-010	Ruby	0.254	20477950018	Diamond	0.460
041759-012	Ruby	0.305	304352-07	Sapphire	0.178	041759-013	Ruby	0.330

High Precision Water Stream

The ruby waterjet orifice controls and focuses ultra-high pressure water before it enters the mixing chamber and cutting nozzle. Accurate orifice size helps create a concentrated water stream, improving abrasive mixing, cutting stability, edge smoothness, and dimensional accuracy.

High Efficiency Cutting Performance

This High Efficiency Waterjet Nozzle Orifice helps reduce water stream loss and supports stable cutting performance. It is suitable for continuous production where clean cutting edges, consistent water flow, and reliable machine operation are important.

Durable Ruby Material

The synthetic ruby insert provides strong hardness and wear resistance under high-pressure working conditions. Its stable structure helps maintain cutting accuracy for longer operation, reducing replacement frequency and maintenance cost.

Suitable Materials

Ruby waterjet orifices can be used for cutting stainless steel, carbon steel, aluminum, titanium, glass, ceramic tile, marble, granite, composite materials, rubber, foam, and engineering plastics. They are suitable for both abrasive Waterjet Cutting Systems and pure waterjet applications.

Compatible Waterjet Systems

This Waterjet Cutting Machine Orifice can be used with many CNC Waterjet Machines, Abrasive Waterjet Systems, pure waterjet systems, and industrial cutting equipment. Different sizes and specifications are available for different pressures, materials, and production needs.

Why Choose KUNDA Waterjet Parts

KUNDA supplies ruby orifices, sapphire orifices, diamond orifices, Waterjet Jewels, Mixing Tubes, Focusing Tubes, cutting heads, high-pressure pump parts, accumulators, high-pressure tubing, and other waterjet spare parts. We support OEM customization, strict quality control, fast delivery, and professional technical service for global waterjet users.

Contact Us

If you are looking for reliable ruby waterjet orifices, high efficiency nozzle components, or wholesale waterjet consumables, please contact KUNDA for more information and professional support.
