Seat WS0013 Good Quality Waterjet Parts Supplier

Short Description:

Seat
900014, MJ2260041, HD210100
Minimum Order Quantity: 1
Availability: Yes
Weight: 0.001 kg
Working Pressure: 4137 bar
Material: Stainless Steel

INQUIRY

Details

Seat WS0013 Good Quality Waterjet Parts Supplier

Part Number	Alternative models	Description
WS0013	900014	Seat
WS0200	1830	Water Nozzle
WS0202	MJ0380244	Focusing Tube
WS0747	HD210800	Valve Body
WS0765		Collimation Tube
WS0923		Focusing Tube
WS0950	HD310500	Collet 6.35 mm
WS1639	901430	On/Off Seal Assembly
WS1884	HD310100	3D Head Housing
WS2266	HD310400	Clamping Nut To Abrasive Head
WS2267	MJ2610003	Clamping Ring For Abrasive Head
WS2269	MJ0760002	V-Seal
WS2529	HD310300	Mixing Chamber
WS2557	MJ4810001	Threaded Tip For Abrasive Supply
WS2723	MJ0380005	Seal For Plug
WS2724	MJ0380006	Plug

The Seat WS0013 is a key sealing component in a waterjet cutting valve assembly, providing a stable seal and support for the valve core. It directly impacts the valve's opening and closing performance and overall sealing performance, playing a crucial role in high-pressure waterjet systems.
A: Product Features

High-strength material: Typically made of high-quality carbide or ceramic, it offers excellent pressure and wear resistance.
Precision machining: The sealing surface undergoes rigorous grinding and polishing to ensure a tight fit with the valve core, preventing leakage.
High-pressure shock resistance: It can withstand high-pressure water flow exceeding 60,000 PSI for extended periods.
Extended valve life: It effectively protects the valve core and internal components, reducing maintenance frequency.
