Seal Head Spacer Ring 05144597 Abrasive Waterjet Parts Supplier

Short Description:

Parts:05144597
Seal Head Spacer Ring,Waterjet Parts

Article number: 11029
Net Weight: 6 g

INQUIRY

Details

Seal Head Spacer Ring 05144597 Abrasive Waterjet Parts Supplier

The 3HAC022379-001-Axis-2-3-For-Robot-Water-Jet-Cutting-Machine-Parts-In-Stock-p.html target='_blank'>Sealing-Head-Spacer-Ring-05144696-Good-Quality-Water-Jet-Parts-p.html target='_blank'>Sealing Head Spacer Ring 05144597 is an OEM stainless‑steel spacer used in KMT Streamline V (75S/100S) Intensifier-Assembly-80072333-Good-Quality-Water-Jet-Parts-In-Stock-p.html target='_blank'>Intensifier pumps to position the high‑pressure seal head precisely on 0.875″ plungers operating at up to 60 000 psi.

Specifications
Part Number: KMT 05144597
Inner Diameter: 1.12 in (28.4 mm) Celcon spacer for 1.13″ plungers
Pressure Rating: Up to 60 000 psi (4 100 bar)
Material: Stainless steel body with Celcon (POM‑C) insert for wear resistance
Weight: ~0.006 lbs (≈2.7 g)

Installation & Maintenance Tips
1.Clean Surfaces: Flush the intensifier cylinder and seal head assembly to remove any grit before disassembly.
2.Inspect Spacer: Verify the spacer ring is undamaged and free of burrs; a deformed spacer causes uneven seal compression.
3.Seal Assembly: Install the spacer between the dynamic seal cartridge and the cylinder head, ensuring its flat face sits flush against the seal head body.
4.Lubrication: Lightly coat seals and spacer surfaces with high‑vacuum 1-11136-Abrasive-Waterjet-Parts-With-Good-Quality-Supplier-p.html target='_blank'>Grease to ease seating and prevent dry start.
5.Torque Pattern: Reinstall the cylinder head, torquing bolts in a star pattern to KMT‑specified values (refer to the SL‑V service manual) to achieve uniform seal compression.
6.Pressure Test: After reassembly, conduct a leak test at 10% above normal operating pressure (≤66 000 psi) to confirm zero leaks before returning to service.
