Sapphire Long Stem 0.25 mm Orifice Assembly 10001225 Abrasive Water Jet Parts For Sale

Short Description:

Parts:10001225
Sapphire Long Stem,0.25 mm Orifice Assembly

Weight: 0.005 kg
Working pressure: 4137 bar
Material: Diamond, stainless steel, titanium or nickel-based alloy
Where is it:
Located in the mixing chamber.
What is its function:
Serves to focus the water jet to the required size.
What is it or what does it consist of:
It is a small part in the form of a truncated cone. It consists of a steel body, a retaining ring and a diaphragm made of corundum (sapphire).

INQUIRY

Details

Sapphire Long Stem 0.25 mm Orifice Assembly 10001225 Abrasive Water Jet Parts For Sale

The Sapphire Long Stem 0.25 mm Orifice Assembly 10001225 is a precision component used in waterjet cutting systems, particularly compatible with KMT-style cutting heads. This assembly features a synthetic sapphire orifice with a 0.25 mm (0.010 inch) inner diameter, providing exceptional wear resistance and maintaining precise flow characteristics under high-pressure conditions.

Key Specifications:
Orifice Diameter: 0.25 mm (0.010 inch)
Material: Synthetic sapphire
Mounting Type: Long stem, designed for KMT-style cutting heads
Compatibility: Replaces KMT part numbers such as A2260010 and 20459568
Applications: Ideal for cutting applications requiring high precision and durability
