SGM7J-08AFC6E Ac Servo Motor For Sale

• Input power supply
• 200 V

• Rated output
• 0.75 kW

• Shaft end
• Straight with key and tap

• Encoder resolution
• 24 bit

• Encoder type
• Incremental

• Options
• With holding brake (24 VDC)

• Height
• 94.7 mm

• Width
• 80 mm

• Depth
• 184 mm

• Weight
• 2.8 kg

• Allowable Load Moment of Inertia
• 12 Times

• Rated torque
• 2.39 Nm

• Instantaneous maximum torque
• 8.36 Nm

• Rated Motor Speed
• 3000 1/min

• Maximum motor speed
• 6000 1/min

• Motor Moment of Inertia
• 1.77 x10⁻⁴ kg·m²

• Flange Dimension (LC)
• 80 mm

• Flange Diameter (LA)
• 90 mm

• Shaft End Diameter (S)
• 19 mm

• Shaft End Length (Q)
• 40 mm

The SGM7J-08AFC6E is a state-of-the-art AC servo motor from SGM, designed to offer superior precision and reliability in demanding industrial automation applications. With a rated power of 0.75 kW and a maximum speed of up to 3000 RPM, this motor is ideal for a wide range of tasks, including robotics, CNC machinery, conveyors, and other high-performance motion control systems.

Built with advanced technology, the SGM7J-08AFC6E features a high torque-to-inertia ratio, ensuring smooth operation and quick response times, even in dynamic applications. Its compact and robust design allows it to deliver exceptional performance while saving space, making it suitable for both new installations and retrofits in existing systems.

The motor incorporates a high-precision encoder that provides excellent feedback and ensures accurate motion control, crucial for applications requiring precise positioning and velocity control. Additionally, it features a high-efficiency design that minimizes energy consumption while maintaining maximum output performance.

Durability is another key feature of the SGM7J-08AFC6E, as it is equipped with an IP67-rated enclosure, offering protection against dust and moisture. This makes it an excellent choice for use in challenging environments, such as production lines and manufacturing floors where reliability is paramount.

The SGM7J-08AFC6E servo motor is compatible with SGM’s drive systems, ensuring seamless integration and optimized performance. Whether you’re upgrading your existing setup or designing a new system, this servo motor offers the reliability, precision, and energy efficiency you need to elevate your automation capabilities.
