Normally Open Pneumatic Valve Assembly 10184760 Waterjet Parts

Short Description:

Parts:10184760
Normally Open Pneumatic Valve Assembly,KMT Waterjet Parts

Without nozzle tube.
KMT part number: 10184760
Article number: 12703
Net Weight: 1548 g

INQUIRY

Details

Normally Open Pneumatic Valve Assembly 10184760-Waterjet-Parts-p.html target='_blank'>10184760 Waterjet Parts

The KMT 10184760 Pneumatic Valve Assembly is a high-pressure, normally open (N/O) 3-port dump valve actuator designed for use in KMT waterjet systems, specifically those operating at 60,000 psi (4,100 bar).

Specifications
Part Numbers: KMT 10184760, WSI VL10184760, AccuStream 1-13244
Type: Normally open (N/O), 3-port pneumatic dump valve actuator
Compatibility: Designed for 60K systems with round, 3-port dump valves
Material: Typically stainless steel for durability and corrosion resistance
Weight: Approximately 4.26 lbs (1.93 kg)
Air Intake: Standard 1/8-27 NPT RH thread
HP Water Inlet: Standard 3/8" HP connection
Suggested Air Pressure: 75–125 PSIG
