The KMT 05069702 Pneumatic Valve Assembly is a high-pressure, normally open (N/O) 3-port dump valve actuator designed for use in KMT waterjet systems, particularly those operating at 60,000 psi (4,100 bar). This assembly plays a crucial role in safely venting pressure from the system during operation.

Specifications
Part Number: 05069702 (KMT), VL05069702 (WSI)
Type: Normally open (N/O), 3-port pneumatic dump valve actuator
Compatibility: Designed for 60K systems with round, 3-port dump valves
Material: Typically stainless steel for durability and corrosion resistance
Weight: Approximately 5.211 lbs (2.36 kg)
Air Intake: Standard 1/8-27 NPT RH thread
HP Water Inlet: Standard 3/8" HP connection
HP Water Outlet: Reduced to standard 1/4" HP connection
Suggested Air Pressure: 75–125 PSIG
