Backup Ring CP020012/591 Water Jet Parts With Good Price

Short Description:

Backup Ring,20-Cp
5100025
Minimum Order Quantity: 1
Availability: Yes
Supplier: KUNDA
Weight: 0.001 kg
Working pressure: 4137 bar
Material: Stainless steel

INQUIRY

Details

Backup Ring CP020012/591 Water Jet Parts With Good Price

Part Number	Alternative models	Description
1-18268	CP020052/220	Safety Bolt
1-16394	CP022045/775	Valve Insert
1-16396	WJ055003/168	Valve Seat
1-18265	WJ055023/527	Guide Bushing
1-18262	WJ070005/551	Valve Stem
4100392	003001008/220	Gear Ring
1-18276	034858/220	Protective O-Ring
	137701/220	Compact Sealing Set
106808	315163080/255	Disc Spring
4100248	34203002/220	Ball
4100021	5219303-220	Spring
107070	560285150/255	Cup Spring
	AB080300	Tee abrasive
4101364	CP020011/150	Sealing Ring
5100025	CP020012/591	Backup Ring
5102089	CP020023/593	Valve Insert
MJ0040080	CP020030/562	Books
106646	CP020031/473	Guiding
106663	CP020032/562	Support Ring
106778	CP020033/255	Compression Spring
106777	CP020034/255	Compression Spring
5102171	CP020066/527	Backup Ring
5102203	CP020071/593	Sealing Cone
5102091	CP020074/593	Sealing Cone
106565	CP022002/190	Cylinder
1-16392	CP022011/150	Sealing Ring
1200395	CP022013/014	Distance Bushing
5100114	CP022016/172	Connection Flange
	CP022017/172	Connection Flange
106564	CP022018/563	Flange

The Backup Ring CP020012/591 is a support component in the high-pressure sealing system of a waterjet intensifier, used in conjunction with an O-ring or sealing ring. It provides support and retention for the seal under ultra-high-pressure operating conditions, preventing extrusion or deformation, thereby ensuring the stability and service life of the sealing system.

Function: Supports and protects the sealing element, preventing failure under high-pressure conditions.
Applicable Location: Installed in the intensifier's high-pressure cylinder seal assembly, in conjunction with an O-ring or sealing ring.
Material: Typically made of high-pressure-resistant engineering plastics or polymers, it offers excellent wear and extrusion resistance.
Replacement Period: As a consumable part, it should be regularly inspected and replaced according to the equipment's operating hours and maintenance schedule to maintain optimal performance of the sealing system.

The high-quality Backup Ring CP020012/591 effectively improves the reliability of the sealing assembly and reduces the risk of leakage, making it an indispensable component for the long-term and stable operation of Water Jet Cutting Machines.
