5-Axis Abrasive Waterjet Head Replacement Assembly for Flow Waterjet Systems
5-Axis Abrasive Waterjet Head Replacement Assembly for Flow Waterjet Systems
Product Introduction
The 5-Axis Abrasive Waterjet Head is a high-performance replacement cutting head assembly designed for advanced CNC Waterjet Cutting Systems. Compatible with Flow Waterjet Machines and various Industrial Waterjet applications, this 5-axis cutting head provides precise multi-angle cutting, dynamic bevel processing, and excellent edge quality for demanding manufacturing environments.
Designed to work with ultra-high pressure Abrasive Waterjet Systems, the cutting head can efficiently process metal, stone, glass, ceramics, composite materials, and engineering plastics while maintaining high cutting accuracy and stable operation. As a professional waterjet spare parts supplier, KUNDA provides reliable replacement assemblies, technical support, and customized waterjet solutions for global users.
Technical Specifications
| A-axis Rotating Range | ±70° |
| C-axis Rotating Range | Infinite |
| Positioning Precision | 1.5' |
| Max Rotational Speed | 50 RPM |
| Cutting Precision at Fixed Point | ±0.05mm |
| Rotating Radius | 261mm |
| Automatic Height Measurement | Optional |
| Max. Height | 607mm |
| Max. Length | 376mm |
| Max. Width | 161mm |
| High Pressure Tube Inlet Threading | 1/4 Inch |
Advanced 5-Axis Cutting Capability
This 5-axis abrasive waterjet head is designed for complex multi-angle cutting operations that are difficult to achieve with standard vertical cutting heads. The advanced motion capability allows the cutting head to automatically adjust cutting angles during operation, making it suitable for bevel cutting, chamfering, weld preparation, and three-dimensional contour processing.
Compatible Replacement for Flow Waterjet Systems
The Flow waterjet 5-axis head replacement assembly is designed to provide reliable compatibility with various Flow waterjet cutting systems and industrial waterjet applications. This replacement assembly helps customers restore cutting performance, improve production efficiency, and reduce machine downtime.
Ultra High Pressure Abrasive Cutting Performance
This Waterjet Cutting Head is engineered to work with ultra-High Pressure Waterjet Pump systems and abrasive cutting applications. The optimized internal flow design helps maintain a stable abrasive stream while improving cutting efficiency and edge quality.
The cutting head can process stainless steel, carbon steel, aluminum, titanium, marble, granite, glass, ceramic tiles, composite materials, and other industrial materials with excellent precision and consistency.
Improved Cutting Accuracy and Edge Quality
The advanced 5-axis cutting technology helps reduce taper and improve edge quality during waterjet cutting. By automatically adjusting cutting angles according to material thickness and cutting paths, the system can achieve more accurate dimensions and smoother finished surfaces.
Durable Industrial Construction
The 5-axis abrasive waterjet head is manufactured with high-quality materials and precision-engineered components to ensure long-term reliability under ultra-high pressure working conditions. The durable construction helps resist wear and maintain stable cutting performance during continuous industrial production.
Easy Installation and System Integration
This replacement cutting head assembly is designed for convenient installation and integration with compatible waterjet systems. It is suitable for equipment upgrades, maintenance projects, and production line improvements. KUNDA can also provide technical support and customization services to help customers achieve optimal cutting performance.
Applications of 5-Axis Waterjet Cutting Heads
- Bevel cutting
- Chamfer cutting
- Weld preparation
- Metal fabrication
- Stone and marble processing
- Glass cutting
- Ceramic tile cutting
- Composite material cutting
- Industrial custom fabrication
Frequently Asked Questions
What is a 5-axis abrasive waterjet head?
A 5-axis abrasive waterjet head is a multi-angle cutting head that allows the nozzle to tilt and rotate during cutting. It is commonly used for bevel cutting, chamfering, taper compensation, and complex contour processing.
Can this cutting head replace a Flow waterjet 5-axis head?
This replacement assembly is designed for Flow waterjet systems and related industrial waterjet applications. For exact compatibility, customers can provide machine model and cutting head photos for confirmation.
What materials can this 5-axis waterjet head cut?
It can cut stainless steel, carbon steel, aluminum, titanium, marble, granite, glass, ceramic, composites, rubber, plastics, and other industrial materials when used with a suitable high-pressure waterjet system.
Does the cutting head support automatic height measurement?
Automatic height measurement can be configured as an optional function according to customer requirements and machine system compatibility.
