High Pressure Water Jet Pump New Good Price Copper Abrasive Waterjet Supplier

Short Description:

Pressure  Range:90,000psi
Low Pressure Filter:10 µm abs.
Voltage:380V
Attenuator capacity:2L
Use for Abrasive Waterjet Cutting Machine
Stable pressure
High Pressure Water Jet Pump,Abrasive Waterjet ,Waterjet





Details

High Pressure Water Jet Pump New Good Price Copper Abrasive Waterjet Supplier

Name

90,000psi Waterjet Pump

Temperature

5-40°C

Pressure  Range

100,000psi

Oil Level and Temperature Control

Sensor

Low Pressure Filter

10 µm abs.

Application

Water jet cutting system

Voltage

380V

Rated power

60hp (45kw)

Attenuator capacity

2L

Nom. Current at 480V/60Hz (Full Load Amp)

70 A

Maximum water flow

0.78 gal/min (2.9 lpm)

Min. Cutting Water Inlet Flow

4.0 gal (15.1 L)

Hydraulic Tank Capacity

220L

Size (L * w * h)

2.2m*1.4m*1.5m


The High Pressure Water Jet Pump for water jet cutting is the core component of modern high-pressure water jet cutting systems and is widely used for precision cutting in industries such as metal, stone, glass, and composite materials. Its main function is to boost the low-pressure water source to a high pressure of 60,000 to 90,000 psi (about 4,100 to 6,200 bar) through the hydraulic booster principle to drive the Water Jet Cutting Head for efficient cutting.
The High Pressure Water Jet Pump uses the oil pressure in the hydraulic system to push the 1-11508-Abrasive-Waterjet-Parts-With-Good-Quality-Supplier-p.html target='_blank'>Piston, which is connected to the plunger. The low-pressure oil pressure is converted into high-pressure water flow through the ratio of the piston area to the plunger area. This boosting principle is similar to the working mechanism of a hydraulic press, that is, the oil pressure multiplied by the piston area is equal to the water pressure multiplied by the plunger area.
Main components High Pressure Water Jet Pump
Hydraulic system: Provides power to push the booster to perform piston movement.
Booster assembly: The core component, which generates high-pressure water flow by hydraulically driving the plunger.
Accumulator: Stores hydraulic energy to ensure the continuous operation of the booster.
Control system: Regulates and monitors the working status of the pump to ensure stable operation of the system.

More details,pleases contact us!!!
