The Flange Mount Proximity Switch (Part # 1-11670) is an inductive position sensor designed for flange mounting on AccuStream/Hypertherm intensifier and Pump assemblies. It provides non-contact detection of metal components—such as the intensifier piston or valve spool—enabling precise end-of-stroke or home-position monitoring.
Specifications
Manufacturer & Part Number: AccuStream 1-11670
Function: Inductive proximity switch for detecting metal targets without physical contact
Mounting Style: Flange-mounted housing for secure attachment to pump or intensifier block
Electrical Characteristics (typical inductive sensor):
Operating voltage 10–30 V DC
PNP normally-open output
Rated switching distance ~15 mm
Protection class IP68/IP69K
Materials: Stainless steel or nickel-plated brass housing (sensor element), polyamide flange
