1/4 Coning and Threading Tool Set 1-15493 Good Quality High Pressure Waterjet Tube Parts

Short Description:

Parts:1-15493
1/4 Coning and Threading Tool Set,Waterjet Tube Parts
Specifications
Tube OD：1/4 in. (6.35 mm)
Thread Size：1/4-28 UNF, left-hand
Material：Hardened tool-steel (die, cutter)
Weight (kit)：≈ 2.5 lbs (1.13 kg)
Temperature Range：−20 °C to +80 °C
Packaging：Plastic case with foam inserts
Kit Contents
Threading Die (1/4″-28 UNF left-hand)
Coning Collet (holds tubing for chamfering)
Coning Cutter (forms precise bevel on tube ends)
Guide Bushing (aligns cutter and die)
Coning &

INQUIRY

Details

1/4 Coning and Threading Tool Set 1-15493 Good Quality High Pressure Waterjet Tube Parts

The AccuStream part 1-15493 is a complete 1/4 inch coning & threading tool set for ultra-high-pressure waterjet tubing, designed to chamfer (“cone”) and cut threads on 1/4″ OD tubing rated up to 60 000 psi.

Specifications
Tube OD：1/4 in. (6.35 mm)
Thread Size：1/4-28 UNF, left-hand
Material：Hardened tool-sTeel (die, cutter)
Weight (kit)：≈ 2.5 lbs (1.13 kg)
Temperature Range：−20 °C to +80 °C
Packaging：Plastic case with foam inserts
Kit Contents
Threading Die (1/4″-28 UNF left-hand)
Coning Collet-1-12276-Abrasive-Waterjet-Parts-With-Good-Quality-Supplier-p.html target='_blank'>Collet (holds tubing for chamfering)
Coning Cutter (forms precise bevel on tube ends)
Guide Seal-Bushing-Assembly-80086630-Water-Jet-Parts-In-Stock-p.html target='_blank'>Bushing (aligns cutter and die)
Coning & Threading Oil (lubrication for smooth cutting)
Instruction Sheet (safety and operational guidelines)

If you need other High pressure pipe fittings,Please contact us!
